4K Ultra HD HDR Blu-ray Player DP-UB150
Upgrade Your 4K TV Experience
Unlock the full potential of your 4K TV with the high-end image and audio technologies packed into this compact model. Features include Ultra HD Blu-ray playback, multi HDR format support, high-resolution audio reproduction, and Dolby Atmos®compatibility.
- Stunning Picture Quality
- Ultra HD Blu-ray Playback (4K/HDR)
- Multi Format HDR
- Supports HDR10, HDR10+ & HLG
- Studio Master Sound
- High-Resolution Audio Playback
|PLAYABLE DISCS||BD-ROM||Ultra HD Blu-ray/ FULL HD 3D/ BD-Video||yes|
|BD-RE/ BD-RE DL (Ver.3)||BDAV/ BDMV/ JPEG/ MPO||yes|
|MKV(H.264/ HEVC)/ MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2)||yes|
|FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3||yes|
|BD-R (Ver.1.3) / BD-R DL (Ver.2)||BDAV/ BDMV/ MKV/ JPEG/ MPO||yes|
|MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2)||yes|
|FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3||yes|
|DVD-R*1/ DVD-R DL*1/ DVD-RW*1||DVD-Video/ DVD Video Recording||yes|
|AVCHD/ MKV(H.264/ HEVC)||yes/ yes* (*DVD-R/ DVD-R DL)|
|MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2)||yes (DVD-R/ DVD-R DL)|
|FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3||yes (DVD-R/ DVD-R DL)|
|JPEG/ MPO||yes (DVD-R/ DVD-R DL)|
|+R*1/ +R DL*1/ +RW*1||Video/ AVCHD||yes|
|CD, CD-R/ -RW||CD-DA/ DTS-CD||yes|
|MKV(H.264/ HEVC)||yes (CD-R/ -RW)|
|MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2)||yes (CD-R/ -RW)|
|FLAC/ WAV/ ALAC/ AIFF/ WMA/ AAC/ MP3||yes (CD-R/ -RW)|
|JPEG/ MPO||yes (CD-R/ -RW)|
|AUDIO SYSTEM||Dolby Audio (Dolby Digital/ Dolby Digital Plus/ Dolby TrueHD)||yes (Decode and Bitstream Output*2)|
|DTS-HD Master Audio/ DTS-HD High Resolution Audio||yes (Decode and Bitstream Output*2)|
|Dolby Atoms/ DTS:X||yes (Bitstream Output*2)|
|FLAC||yes (Max. 192 kHz/ 24 bit)|
|WAV||yes (Max. 384 kHz/ 32 bit)|
|ALAC||yes (Max. 192 kHz/ 32 bit (2ch))|
|DSD (DFF, DSF)||yes (2.8 MHz (2ch/ 5.1ch), 5.6 MHz (2ch/ 5.1ch), 11.2 MHz (2ch))|
|AIFF||yes (Max. 384 kHz/ 32 bit (2ch))|
|Front||1 (USB 2.0 High Speed)|
|Playback||FLAC/ WAV/ ALAC/ AIFF/ DSD (DFF, DSF)/ WMA/ AAC/ MP3||yes|
|MKV(H.264/ HEVC)/ MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC)||yes|
|PS (MPEG-2) / AVCHD/ AVCHD 3D||yes|
|HIGH QUALITY PICTURE||4K Networking (4K Video*6 Playback/ 4K JPEG Playback*4)||yes|
|Hybrid Log Gamma(HLG)||yes|
|4K Up-scaling||60p/50p/ 4:4:4 (HDMI2.0)||yes*4*5|
|SMART FEATURE||Remote Control||yes (Simple)|
|HDAVI Control 5 (VIERA Link) / HDMI CEC||yes (HDMI CEC only)|
|External HDD Playback||yes*14|
|TERMINAL||HDMI Output||yes (1)|
|LAN (Ethernet) Terminal||yes (for Ultra HD Blu-ray, BD-Live™*15 and Firmware Update)|
|OTHERS||Video System||PAL/ NTSC|
|Power Supply||AC 220-240 V, 50 Hz|
|Power Consumption||Normal Use||12 W|
|Standby (Quick Start Off)-Network Standby Off||0.3 W|
|DIMENSIONS, WEIGHT||Dimensions (W x H x D)||320 x 46 x 193 mm *17|
|NOTIFICATION||NOTE||*1 Discs recorded and finalized on recording devices.
*2 HDMI connections and compatible equipment (e.g. AV Receiver) required.
*3 Enabled by software update
*4 For 4K Up-scaling playback a TV with same resolution is required.
*5 For 4K/60p video, a high speed HDMI cable supporting 18 Gbps bandwidth is required.
*6 MP4(4K/25p,30p) bit rate up to 100 Mbps/resolution up to 3840x2160.
*7 Some network content services may not be available in your country.
*8 Ultra HD Blu-ray and Photo (JPG/ MPO) are not supported.
*9 This function is effective only when reproducing AVCHD data recorded with x.v.Color technology. The function cannot be used with BD-ROM or DVD-ROM discs. HDMI connection is required.
*10 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
*11 CD sampling is done at 176.4/88.2 kHz.
*12 A device that supports the Mirroring function and Android™ ver. 4.2 or higher is required.
*13 Requires broadband Internet service.
*14 The external HDD with capacities of 4TB or less in processing NTFS/ FAT32 data is supported. Playback is not possible with some external hard disk drives.
*15 To enjoy content, you will need to insert a USB (1GB or more of free space/ sold separately). Requires broadband Internet service.
*16 The analog 2-channel output terminal can also be used as an analog 7.1-channel output terminal.
*17 Excluding the projecting parts.
Specifications are subject to change without notice. All numbers given here are approximate.
|WARNING||The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback.
Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use.
Specifications are subject to change without notice.
