    In-ceiling speakers can be used to get great quality audio for any room while remaining out of sight. We carry brands such as Bowers & Wilkins, Yamaha, PSB, Triad, & Monitor Audio.

    Todds recommends

    This is the top In-ceiling Speakers product we're loving at the moment...

    Bowers & Wilkins CCM7.5 S2 180mm 2-way In Ceiling Speaker (each)
    Bowers & Wilkins CCM7.5 S2 180mm 2-way In Ceiling Speaker (each)
    Bowers & Wilkins CCM7.5 S2 180mm 2-way In Ceiling Speaker (each)

    Bowers & Wilkins CCM7.5 S2 180mm 2-way In Ceiling Speaker (each)

    Regular price$999.00
    /
    Tax included.

    • Low stock - 4 items left
    • Inventory on the way

    See nothing, hear everything

    Designed for down-firing, in-ceiling use, CCM7.5 S2 can be used as the left, centre, right and rear-channel rear speakers in a discreet home cinema system. Its configuration includes a 25mm (1in) Carbon Dome tweeter and a 180mm (7in) Continuum cone mid/ bass cone angled to the mounting surface, allowing for easy direction of the whole array towards the listener to ensure they hear the correct balance of sound. That way, dialogue is crystal clear and special effects come across accurately. Thanks to Bowers & Wilkins unique QuickDogsTM fixing method, installation is simple and if preferred, the supplied round grille can be replaced with an optional, square grille.



    Technical Specifications

     Technical features

    Carbon Dome tweeter

    Continuum mid/bass

    Description

    2-way in-ceiling system

    Drive units

    1x ø25mm (1in) Carbon Dome high-frequency

    1x ø180mm (7in) Continuum cone mid/bass

    Frequency range (-6dB)

    -6dB at 25Hz - 33kHz

    Frequency Response -3dB

    32Hz - 28kHz ±3dB

    Sensitivity

    90dB spl (2.83Vrms, 1m)

    Harmonic distortion

    2nd and 3rd harmonics (90dB, 1m)

    <1% 70Hz - 33kHz

    <0.5% 100Hz - 28kHz

    Nominal impedance

    8Ω (minimum 4.8Ω)

    Recommended amplifier power

    25W - 150W into 8Ω on unclipped programme

    Frame diameter

    290mm (11.4in)

    Depth (behind surface)

    128mm (5in)

    Cut-out diameter

    254mm (10in)

    Protrusion

    8.5mm (0.33in)

    PMK

    PMK C8

    Back box

    BB 6C

    Square grille option

    GR68SQ

    Net weight

    3.1kg (6.83 lb)

    Finishes

    Grille: White

    In-ceiling Speakers

    A little more info

    In-ceiling Speakers

    In-ceiling speakers can be used to get great quality audio for any room while remaining out of sight. We carry brands such as Bowers & Wilkins, Yamaha, PSB, Triad, & Monitor Audio. They can be used for multi-room audio with music streaming throughout your home or used in a home theatre system as surround channels or to compliment your Dolby ATMOS enabled media room.

    Talk to the team at Todds HiFi about selecting the right in-ceiling speakers & matching amplifiers for your scenario.
