Hi-Fi authenticity in this compact unit systems from the renowned Yamaha PianoCraft range. An aluminium front panel and Burr-Brown DACs reflect a commitment to sound quality for all audio sources.
Connect wirelessly via Bluetooth for quick and simple audio playback from smartphones and other Bluetooth devices. Whether listening to your favourite music streaming services on your phone or watching videos on your tablet, get the most out of your sound by streaming it to your micro Hi-Fi system.
Playback of 192 kHz / 24-bit FLAC and WAV files via USB reflects the Hi-Fi origins of this system. This support offers listeners the ability to experience the best in Hi-Fi listening.
The PianoCraft series has for many years, embodied authentic Hi-Fi performance from a compact unit. Inheriting design philosophies from Yamaha Hi-Fi components ensure quality Hi-Fi performance from any PianoCraft product.
The MCR-B270D maintains the design image of Yamaha Hi-Fi components - presenting an extremely high-class, sophisticated appearance.
The centre unit has a front panel made of high-grade aluminium with a hairline finish that looks clean and elegant. Adding this stylish system to your room will enhance not just your listening but your home décor as well.
To prevent unwanted cabinet vibration, Yamaha developed an internal structure called VCCS (Vibration Control Cabinet Structure) that employs strategically placed pieces of a composite material providing excellent vibration isolation performance.
DAB+ digital radio offers a large selection of radio stations with high-quality sound.
Other benefits include automatic tuning to available stations and display of information such as station name.
*Availability of service varies by region.
|Center Unit||Bluetooth Version/Profile||Ver. 4.2 / A2DP, AVRCP ; [Audio Codec] SBC, AAC|
|Bluetooth Maximum Communication Range||10 m / 32.8 ft. 10 in. (without interference)|
|Disc Type||CD, CD-R, CD-RW (Audio CD, MP3, WMA)|
|File Format||MP3, WMA, AAC, WAV(*1), FLAC(*1), AIFF(*1), ALAC(*2) --- (*1) 192 kHz / 24-bit; (*2) 48 kHz / 24-bit|
|Tuner||DAB+ / FM|
|Preset Memory||DAB+ x 30 / FM x 30|
|Headphone Jack||Yes (6.3 mm)|
|Analog Audio Input||Yes (3.5 mm STEREO mini Jack × 1)|
|Digital Audio Input: Optical||Yes|
|Total Harmonic Distortion(CD to Sp Out, 20 Hz-20 kHz)||0.05 %|
|Output Power/Channel (6 ohms, 1 kHz, 10% THD)||20 W + 20 W|
|Standby Power Consumption||0.3 W (Eco standby) / 1.3 W (Bluetooth® standby on)|
|Dimensions (W x H x D)||180 x 118 x 322 mm; 7-1/8” x 4-5/8” x 12-5/8”|
|Weight||2.7 kg; 5.9 lbs.|
|Speaker System||Woofer||11 cm (4-3/8") cone woofer|
|Tweeter||2.5 cm (1") dome tweeter|
|Input Power (Max/Nominal)||30 W (Nominal)|
|Frequency Response||60 Hz-30 kHz|
|Sensitivity||84 dB / 2.83 V / 1 m|
|Crossover Frequency||6 kHz|
|Dimensions (W x H x D)||123 x 192 x 298 mm; 4-7/8” x 7-1/2” x 11-3/4”|
|Weight||2.2 kg; 4.9 lbs.|
